ZH4102C boat engine 4-cylinder water-cooled 340kg fishing boat main engine with strong power and worry free after-sales service
型号Model ZH4102C 标定功率及相应转速(KW/r/min)Rated Power and Corresponding Speed 30/1500 30/1800 32/2000 34/2400 36/2600 44/2800...
Category Marine Diesel Engine
Keywords diesel engine, boat engines, 4 stroke engine, 4 cylinder diesel engine, boat engine 4 stroke
Email Now
Call Us / Whatsapp
ZH4102C boat engine 4-cylinder water-cooled 340kg fishing boat main engine with strong power and worry free after-sales service
| 型号 Model |
ZH4102C | |||||
| 标定功率及相应转速(KW/r/min) Rated Power and Corresponding Speed |
30/1500 | 30/1800 | 32/2000 | 34/2400 | 36/2600 | 44/2800 |
| 最高空载转（r/min） Maximum No‑load Speed (r/min) |
1578 r/min(50hz) | 1894 r/min(60hz) | 2105 r/min(50hz) | 2526 r/min(50hz) | 2736 r/min(50hz) | 2947 r/min(50hz) |
| 最低空载转速（r/min） Minimum No‑load Speed (r/min) |
650（r/min） | |||||
| 型式 Type |
直列、水冷、四冲程 Inline, Water-cooled, Four-stroke |
|||||
| 进气方式 Air intake mode |
自然吸气 Inhalenaturally |
|||||
| 燃烧方式 Combustion mode |
涡流 eddy current |
燃烧式 Combustion Type |
||||
| 缸径*行程（mm） Bore*troke (mm) |
 100×115（mm) |
|||||
| 气缸数 Number of Cylinders |
4 | |||||
| 排量（L） Displacement（L) |
3.62(L) | |||||
| 气缸工作顺序 Firing Order |
1-3-4-2 | |||||
| 调速方式 Speed control method |
机械全程调速 Mechanical full-range governing |
|||||
| 冷却方式 Combustion Mode |
闭式强制水循环冷却系统 Closed forced circulation water cooling system |
|||||
| 连接方式 Connection Type |
飞轮壳（专用飞轮） Flywheel housing (special flywheel) |
|||||
| 压缩比 Net Weight（kg） |
19:01 | |||||
| 机油消耗率（克/千瓦*时） oil consumption rate（g/kW·h） |
≤2.02（g/kW·h） | |||||
| 燃料类型 Fuel Type |
柴油 Diesel |
|||||
| 启动方式 Startup Mode |
24v电启动 24v electric start |
|||||
| 机油等级 Oil Grade |
优于CD15W/40 Better than CD 15W‑4 |
|||||
| 曲轴旋转方向 Rankshaft rotating direction (face to output end) |
逆时针（自飞轮端） Anticlockwise（View from flywheel end） |
|||||
| 标定转速机油压力 Oil Pressure at Rated Speed |
0.2-0.4（MPa) | |||||
| 怠速时机油压力 Oil pressure at idle speed |
≥0.05（MPa) | |||||
| 润滑方式 Lubrication Method |
压力飞溅复合式 Pressure splash composite |
|||||
| 燃油消耗率（克/千瓦*时） Fuel Consumption rate（g/kW·h） |
≤258.4（g/kW·h） | |||||
| 净质量（kg） Net Weight（kg） |
340(kg) | |||||
